| MODEL |
MS-1000-12 |
MS-1000-24 |
MS-1000-36 |
MS-1000-48 |
| OUTPUT |
DC output voltage |
12V |
24V |
24V |
48V |
| Rated current |
66.6A |
41.6A |
27.78A |
20.8A |
| Current range |
0-66.6A |
0-41.6A |
0-27.78A |
0-20.8A |
| DC power |
800W |
1000W |
1000W |
1000W |
| Voltage ADJ.range |
±10% |
±10% |
±10% |
±10% |
| Voltage tolerance |
±1% |
±1% |
±1% |
±1% |
| Ripple and noise |
150mVp-p |
240mVp-p |
240mVp-p |
480mVp-p |
| Intet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±5% |
±0.5% |
±0.5% |
±0.5% |
| INPUT |
AC voltage range |
85~132VAC/170~264VAC selected by switch 47~63Hz |
| Current |
8A/230V |
| Efficiency |
77% |
82% |
82% |
83% |
| AC Inrush current |
75A/230V |
| Leakage current |
<3.5mA/240VAC |
| PROTECTION |
Overload |
Protection type : Constant current limiting, recovers automatically after fault condition is removed |
| Over-voltage |
115%~135% Protection type :Shut off |
| 13.8-16.2V |
27.6~32.4V |
41.4~48.6V |
55.2~64.81 |
| High-temperature |
ERH3 ≥ 55°C Fan on,≤ 45°C Fan off,≥ 70°C,Cut down output(5~15V) |
| SAFETY |
Setup,rise,hold up time |
1.5ms,50ms,20ms |
| Vibration |
10~500Hz,2G 10min,/1 cycle |
| Withstand voltage |
Input and output interval:1.5KVAC,Input and enclosure:1.5KVAC,Output and enclosure,0.5KVAC |
| Isolation resistance |
Input and output interval:Input and enclosure,Output and enclosure:500VAC/100M Ohms |
| ENVIRONMENT |
Temperature coefficient |
±0.03%/°C (0~50°C ) |
| Working temperature and humidity |
-10°C ~+60°C,20%~90%RH |
| Store temperature and humidity |
-20°C ~+85°C,10%~95%RH |
